WBT-0114 Cu — nextgen™ RCA Plug, White (Left)

A carefully engineered RCA connector built around WBT’s nextgen™ approach: low-mass pure-copper signal conductors, high contact pressure and a robust clamping mechanism for a secure, consistent connection.

The WBT-0114 Cu combines a mechanically stable body with deliberately low-mass signal paths. Its patented clamping mechanism adapts to different RCA socket dimensions while maintaining high contact pressure and very low transition resistance. The brass outer sleeve provides effective electromagnetic shielding.

Specifications

• Pure copper signal conductors
• 24k nickel-free direct gold plating
• 75 Ω characteristic impedance up to 400 MHz
• Suitable for analogue and digital RCA connections
• Patented WBT clamping mechanism
• Cable entry up to 9 mm
• Solder connection
• Length: 51 mm
• Outer diameter: 13.6 mm
• Made in Germany

Sold individually.
